Product Description:
These tricone roller bits are ideal for horizontal directional drilling and oil and gas extraction, making them a versatile choice for a variety of drilling applications. With their ability to handle tough terrain and provide high-quality drilling performance, these bits are a must-have for any drilling operation.
These tricone drill bits come with a 1-year warranty, ensuring that you can rely on their performance and durability for years to come. Additionally, they are available for viewing at our showroom location in Hebei, China, allowing you to see them up close and in person before making a purchase.
These tricone roller bits come with a 3 1/2 API Reg thread, making them easy to install and compatible with a wide range of drilling equipment. With their reliable performance and ease of use, these tricone drill bits are an excellent choice for any drilling operation.
Features:
Strong adaptability to different strata: Capable of dealing with soft, medium and hard strata, including complex geological conditions with interlayers.
High rock-breaking efficiency: The combined effects of impact, crushing and shearing, resulting in a higher mechanical drilling rate (ROP) than that of other drill bits (such as PDC drill bits) in certain formations.
Resistant to high drilling pressure: Suitable for deep and ultra-deep well operations, capable of withstanding large axial loads.
High cost-performance ratio: The initial purchase cost is lower than that of PDC drill bits, and the maintenance and replacement are relatively convenient.
Technical Parameters:
| Product Attribute |
Value |
| Product name |
Tricone Drill Bits |
| Processing Type: |
Forging |
| Showroom Location: |
Hebei, China |
| Dimensions Of Three Cone Drill Bits: |
3-26 Inches |
| Warranty: |
1 Year |
| Overall Length: |
Oil-based Geology , Water-based Geology |
| Kumulierte Dauer: |
≥80 Hour |
| Applicable Industries: |
Construction Works , Energy & Mining |
| Advantage |
High-efficiency ,wear resistant |
| Usage: |
Horizontal Directional Drilling , Oil And Gas Extraction |
Applications:
1. Well drilling and irrigation well drilling
When drilling wells in hard strata such as mountainous areas and deserts, the three-cone bit can quickly penetrate the gravel layer and weathered rock layer. Compared with the PDC bit, it is more suitable for uneven strata and reduces the risk of sticking.
2. Foundation pit support and anchoring engineering
For anchor bolt holes in deep foundation pits (diameter 100-150mm), the small three-cone bit is used in combination with a submersible hammer to achieve efficient hole formation in sandy soil and moderately weathered rock layers.
Customization:
Brand Name: RuiTong Bit
Model Number: TCI tricone bit
Place of Origin: Hebei, China
Certification: API/ISO9001
Minimum Order Quantity: 1pcs
Price: Negotiable
Packaging Details: According to customer needs
Delivery Time: 15-30 work days
Payment Terms: T/T,L/C
Supply Ability: 50 pcs per month
Usage: Horizontal Directional Drilling, Oil And Gas Extraction
Warranty: 1 Year
Overall Length: Oil-based Geology, Water-based Geology
Dimensions Of Three Cone Drill Bits: 3-26 Inches
Showroom Location: Hebei, China
Packing and Shipping:
Product Packaging:
- Each tricone drill bit is individually packaged in a sturdy box for maximum protection during shipping and handling.
- The box includes detailed instructions on how to use and maintain the drill bit.
Shipping:
- All orders are processed within 24 hours and shipped via express courier to ensure timely delivery.
- Shipping costs are calculated based on the destination and weight of the package.
- Customers can track their package using the tracking number provided.
- If there are any issues with the delivery, customers can contact our customer service team for assistance.
